Estes Rockets

E12-6 Engines

Sku: 001693
$26.49
Sale

ENGINES FOR MODEL ROCKETS


3 – E12-6 Engines
4 – Starters
4 – Starter Plugs

ATTENTION: These engines cannot be sent to post office boxes. Please be sure to provide a PHYSICAL ADDRESS when purchasing E and F sized engines.

Overview

Recommended Rockets

Specs

Reviews

Overview

The Estes E12-6 engine is a 24mm diameter upper stage engine designed for model rocket flight. This engine can also be used as a single stage engine. Maximum lift weight is 14 ounces. Each package includes 3 engines, 4 starters and 4 starter plugs.

ATTENTION: Residents of California, New Jersey, Rhode Island and North Dakota please review the Terms of Sale for state specific restrictions or Click Here for State Specific Restrictions.

Overview

Compatible Rockets

SA-2061 Sashaâ„¢
$32.99
Hi-Flier® XL
$23.99
Big Daddyâ„¢
$37.99

Technical Specifications

Technical Specifications

  • Total Impulse

29.50 N-sec

  • Time Delay

6 Seconds

  • Max Lift Weight

14.0 oz (397 g)

  • Max Thrust

29.60 Newtons (6.7 lbs)

  • Thrust Duration

2.70 Seconds

  • Length

3.8 in. (9.7 cm)

  • Diameter

24 mm

  • Weight

2.23 oz. (63.2 g)

  • Propellant Weight

1.3 oz (36.9 g)

Customer Reviews

Based on 3 reviews
100%
(3)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
S
Sam Hofmann
Crazy

I recently used this engine on my custom built rocket the rocket ways 112 grams I have not launched it yet but I will use my altimeter to see how high it goes I also used 12 inch parachute for it. I’m hoping that it will be big enough.

F
Frank

These will work great for my rockets

J
James
Used with my Modified Crossfire ISX (along with an E

Used with my Modified Crossfire ISX (along with an E launch controller and launch pad, obviously) and it went crazy high. I don't have an altimeter on that one right now but it was well out of sight for a while. I was able to recover thanks to the large launch site.
I will also be launching a new Mean machine, too and I'm really excited for that! I'll launch that one on these and on some aerotech F motors if I get ambitious.
