Estes C11-5 Model Rocket Engines
C11 Model Rocket Engine Thrust Curve Chart
Model Rocket Thrust Curve Example
Estes C11-5 Model Rocket Engines
C11 Model Rocket Engine Thrust Curve Chart
Model Rocket Thrust Curve Example
Estes Rockets

C11-5 Engines

SKU: 001523
$9.99
Sale

ENGINES FOR MODEL ROCKETS

2 – C11-5 Engines
2 – Starters
4 – Starter Plugs

PLEASE NOTE: You must have a physical address for delivery.

Overview

Recommended Rockets

Specs

Reviews

Overview

The Estes C11-5 engine is a single stage engine designed for model rocket flight. This engine is a 24mm diameter engine designed for rockets with a maximum lift weight of less than 5 ounces.

Each package includes 2 engines, 2 starters and 4 starter plugs.

ATTENTION: Residents of California, New Jersey, Rhode Island and North Dakota please review the Terms of Sale for state specific restrictions or Click Here for State Specific Restrictions.

Overview

Estes C11-5 Model Rocket Engines

Compatible Rockets

  • Green Eggs with Bag

    Green Eggs™

    Sold out

    Green Eggs™

    $23.99
    $23.99 $23.99
    Sold out
  • SA-2061 Sasha™

    SA-2061 Sasha™

    SA-2061 Sasha™

    $32.99
    $32.99 $32.99

Technical Specifications

Technical Specifications

  • Total Impulse

10.00 N-sec

  • Time Delay

5 Seconds

  • Max Lift Weight

5.0 oz (142 g)

  • Max Thrust

22.10 Newtons (4.9 lbs)

  • Thrust Duration

0.80 Seconds

  • Length

2.75 in. (7 cm)

  • Diameter

24 mm

  • Weight

1.18 oz. (33.5 g)

  • Propellant Weight

0.44 oz (12.4 g)
C11 Model Rocket Engine Thrust Curve Chart

Customer Reviews

Based on 1 review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
100%
(1)
P
Philip Nubel
Bad Lots of C11-5 engines shipped to me

Estes shipped me C11-5 motors from a lot that had a "potential manufacturing issue", E22 1022
